Materials
Polyvinylidene fluoride
All products
An overview of our PVDF products
Polyvinylidene fluoride (abbr. = PVDF) is a semi-crystalline thermoplastic belonging to the group of fluoropolymers.
The fluorine content is slightly more than half.
In general, fluoropolymers are the high performers in plastics and chemical process engineering
because their fluorine content gives them increased chemical and thermal resistance.
A distinction is made between partially fluorinated polymers, such as PVDF, and fully fluorinated polymers, such as PFA.
The higher the fluorine content, the better the chemical and thermal properties.
The strong bond between highly electro-negative fluorine and carbon is the reason
for the high chemical resistance of partially fluorinated PVDF.
In addition to the standard PVDF types, KVG also has the special types PVDF-el (electrically conductive)
and PVDF-flex (= PVDF copolymer) available in stock.
Are you looking for PVDF for your liner application? You are welcome to arrange a call-back with us via our website or contact us in writing by email via verkauf@kvg-staudt.de. Our team will be in touch with you shortly.
Pipes
- Pipe length: 5000/6000 mm
- Also possible as a section
- Pre-treated (CV) or untreated
Please enter the identifier of the table.
Capstrips
Cap strips are used to cover and laminate weld seams and are available in various versions.
- As rolls (max. 20 m) or sections with a width of 1250 mm or 1500 mm
- As pre-cut cap strips with a width of 10 mm or 40 mm
- As glass-laminated or stretch-laminated cap strips
| Dimensions | PVDF SK 0,5 | PVDF GK 0,8 |
|---|---|---|
| 10000x5 | x | |
| 10000x10 | x |
Sheets
Semi-finished products in different versions
- Without lamination in natural or black (PVDF-el)
- With glass lamination or stretch lamination
- Special dimensions and versions available on request
| Thickness | Dimensions | Standard | (SK+) + DS | GK | el | el GK | GGS |
|---|---|---|---|---|---|---|---|
| 0,5 | 10000x1250 | x | |||||
| 1 | 2000x1000 | x | |||||
| 1,5 | 2000x1000 | x | |||||
| 2 | 2000x1000 | x | |||||
| 3 | 2000x1000 | x | |||||
| 2000x1250 | x | ||||||
| 3000x1500 | x | x | x | x | |||
| 20000x1500 | x | ||||||
| 4 | 2000x1000 | x | |||||
| 2000x1250 | x | ||||||
| 3000x1500 | x | x | x | ||||
| 20000x1500 | x | x | |||||
| 25000x1500 | x | ||||||
| 5 | 2000x1000 | x | |||||
| 2000x1250 | x | ||||||
| 3000x1500 | x | x | x | ||||
| 6 | 2000x1000 | x | |||||
| 2000x1250 | x | ||||||
| 3000x1500 | x | x | x | ||||
| 8 | 2000x1000 | x | |||||
| 2000x1250 | x | ||||||
| 3000x1500 | x | ||||||
| 10 | 2000x1000 | x | x | ||||
| 2000x1250 | x | ||||||
| 3000x1500 | x | ||||||
| 12 | 2000x1000 | x | |||||
| 2000x1250 | x | ||||||
| 15 | 2000x1000 | x | |||||
| 2000x1250 | x | ||||||
| 3000x1500 | x | ||||||
| 20 | 2000x1000 | ||||||
| 2000x1250 | x |
Welding wire
Welding wire available in different versions
- As round wire on spool or loose ring
- As triangular welding wire on request
- Colour: natural or black (PVDF-el)
| Diameter [mm] | PVDF, red/pure | PVDF el |
|---|---|---|
| 3 | x | x |
| 4 | x | x |
